This is a user manual for a window air conditioner. It mainly introduces the installation and use methods and precautions.
This manual covers safety guidelines, required electrical protection, and proper installation procedures for the Sampo AW‑2203BR, AW‑2253BR and AW‑2325BR split‑type air‑conditioners. It includes detailed steps for mounting the indoor and outdoor units, wiring requirements, and recommended clearances to ensure optimal performance.
Operating instructions describe how to use the micro‑computer controller, set temperature, select modes (cooling, de‑humidification, fan), and access additional functions such as timer and sleep mode. Maintenance tips and troubleshooting notes are also provided. This manual is written in Chinese.
| Indoor IP rating | IPx0 |
|---|---|
| Outdoor IP rating | IPx4 |
| Operating temperature (hot side) | 21 °C – 43 °C |
| Operating temperature (cold side) | 21 °C – 32 °C |
| Input voltage (110 V model) | 198 V – 242 V |
| Power cable cross‑section | 3.5 mm² or 2.0 mm² (single core copper) |
| Ground wire cross‑section | ≥2.5 mm² |
Press the <运转/停止> key on the micro‑computer controller to start or stop the unit.
The indoor unit has an IP rating of IPx0, while the outdoor unit is rated IPx4.
The hot side can operate from 21 °C to 43 °C, and the cold side from 21 °C to 32 °C.
Use a supply voltage between 198 V and 242 V for the 110 V version.
