The manual covers all steps needed to install the AW‑D20R1 air‑conditioning unit, including site preparation, mounting, electrical connections, and required clearances. It also explains how to operate the remote controller, adjust temperature settings, and perform routine cleaning.
Safety guidelines, troubleshooting tips, and detailed specifications are provided to ensure reliable performance and safe service. The document includes wiring diagrams, recommended ground wire size, and recommended installation height for optimal operation. This manual is written in Chinese.
| Model | AWD20R1 |
|---|
Use a ground wire of 2.5 mm² or larger.
The indoor inlet should have at least a 50 cm clearance from any obstruction.
