This manual explains how to safely set up and operate Sampo's multimedia liquid crystal monitors. It covers warnings, proper placement, power connection, and basic cleaning instructions.
Detailed sections describe menu navigation, audio and video input options, mounting guidelines, technical specifications for the 22‑inch and 26‑inch models, and troubleshooting tips for common issues such as no picture or abnormal colors. This manual is written in Chinese.
| Screen size (22型) | 21.6" diagonal |
|---|---|
| Aspect ratio (22型) | 16:9 |
| Resolution (22型) | 1366 × 768 |
| Brightness (22型) | 400 nits (typ.) |
| Contrast ratio (22型) | 800:1 |
| Response time (22型) | 5 ms (gray‑to‑gray, typ.) |
| Input voltage (22型) | AC 100‑240 V, 1.5 A max |
| Operating power (22型) | < 62 W |
| Standby power (22型) | < 1 W at AC 110 V |
| Built‑in speaker (22型) | 2 × 2 W |
| Screen size (26型) | 26" diagonal |
| Brightness (26型) | 500 nits (typ.) |
| Response time (26型) | 8 ms (gray‑to‑gray, typ.) |
| Input voltage (26型) | AC 100‑240 V, 3.5 A max |
| Operating power (26型) | < 200 W |
| Built‑in speaker (26型) | 2 × 3 W |
Press the MENU button, then use the volume + and volume – keys to navigate to Brightness, Contrast, Sharpness, Saturation, Hue, and Color Temperature and adjust each value.
Verify that the correct video input (HDMI, VGA, D‑VI, etc.) is selected and that the cable is securely connected to both the monitor and the source device.
Yes, the monitor has a wall‑mount hole; use a standard VESA mount that can support at least 48.5 kg.
