The magicolor 4650EN/4650DN series are high‑performance color laser printers offering 24 ppm in both color and black‑white, up to 9600 × 600 dpi PhotoArt resolution, and a 500 MHz processor with dedicated ASIC image processing. They support a wide range of media sizes, network protocols (including IPv4/IPv6), and operating systems such as Windows, macOS, Linux and NetWare.
The manual covers performance parameters, installation steps, paper handling, consumables, network configuration, power consumption, environmental requirements, and the optional PageScope management software. It also details duplex capabilities (built‑in for the 4650DN, not for the 4650EN) and provides troubleshooting and maintenance guidance. This manual is written in Chinese.
| Print speed (color / black‑white) | 24 ppm |
|---|---|
| Resolution (standard) | 600 × 600 dpi |
| Resolution (PhotoArt) | 9600 × 600 dpi |
| Processor | 500 MHz |
| Standard memory | 256 MB |
| Maximum memory | 768 MB |
| Maximum monthly print load | 90 000 pages |
| Power consumption (max) | 1200 W |
| Power consumption (average) | 550 W |
| Dimensions (W × D × H) | 536 mm × 469 mm × 385 mm |
| Weight | 31 kg |
| Network interface | 10/100/1000Base‑T Ethernet |
| USB interface | USB 2.0 (high speed) |
The printer can handle up to 90 000 pages per month.
The magicolor 4650DN model includes a built‑in duplex unit; the 4650EN model does not support duplex printing.
Maximum power consumption is 1200 W, average 550 W, standby 140 W, and energy‑saving mode 16 W.
