This document is a product manual from EIZO NANAO CORPORATION, providing detailed information on how to use the product safely and effectively, including display installation and basic usage information. The manual includes product specifications and precautions, such as usage recommendations, cleaning instructions, and touch screen usage warnings.
The EIZO FDX1501 is a 15-inch color LCD monitor supporting 1024 × 768 resolution. The FDX1501T touchscreen variant has a resistive-film touchscreen compatible with Microsoft Windows 7, Vista, XP, and 2000. The manual says to allow the display at least 30 minutes to stabilize after power-on before making adjustments.
The document covers the EIZO LCD Utility Disk, basic controls, screen and color adjustment, FineContrast modes, input switching, power-saving settings, and monitor information. It also provides cleaning precautions, backlight-life guidance, connection instructions for multiple computers, and troubleshooting. This manual is written in Chinese.
| Display size | 15 inches |
|---|---|
| Supported resolution | 1024 × 768 |
| Backlight | LED backlight |
| Touchscreen | Resistive-film touchscreen on FDX1501T |
| Touchscreen operating system compatibility | Microsoft Windows 7, Vista, XP, and 2000 |
| Operating temperature | 0°C to 50°C (32°F to 122°F) |
| Operating humidity | 20% to 90% relative humidity; wet-bulb temperature below 39°C (102°F), no condensation |
The FDX1501T has the resistive-film touchscreen; this feature is specified for FDX1501T only.
Allow the display at least 30 minutes to stabilize after switching it on before adjusting it.
Use a soft cloth, such as cotton cloth or lens-cleaning paper, to clean the panel.
Contact your dealer when the display becomes dim or starts flickering.
