The D6F-03A3-000 is a MEMS airflow sensor. It has a pressure loss of 0.045kPa, a weight of 5.3g, and an operating environment humidity of 35-85%RH.
The D6F-03A3 is a thin, compact MEMS flow sensor offering high‑precision flow measurement in a small package. It supports a flow range of 0‑3 L/min and is designed for use with DC12‑24 V supply.
The manual includes electrical connection diagrams, performance specifications such as accuracy and pressure rating, operating and storage temperature limits, and part numbers for related components. This manual is written in Japanese.
| Flow range | 0‑3 L/min |
|---|---|
| Supply voltage | DC12‑24 V (max 15 mA) |
| Accuracy | ±0.596 % FS |
| Maximum pressure rating | 30 kPa |
| Operating temperature range | -10 °C to +50 °C |
| Storage temperature range | -10 °C to +60 °C |
The sensor measures flow from 0 to 3 L/min.
It operates on a DC12‑24 V supply with a maximum current of 15 mA.
The sensor can operate between -10 °C and +50 °C.
It is rated for a maximum pressure of 30 kPa.
