D6F-P MEMS flow sensor is a MEMS technology based, small size, light weight, high precision, multiple power supply methods of the sensor, used to measure the flow of air.
The D6F-P MEMS flow sensor is a compact, high‑precision device with excellent environmental durability. It offers several connector options, including a plug‑type connector, a wire‑lead type that mounts directly to a PCB, and a double‑head connector for flexible installation.
The manual lists key specifications such as a flow range of 0–1 L/min, ±5 %FS accuracy, DC 4.75–5.25 V supply voltage, 0–5 V output signal, IP40 protection, and operation from –10 °C to 60 °C with 35–85 % RH. Physical details include a PBT housing, a weight of about 3 g, and a pressure loss of roughly 0.3 kPa. This manual is written in Chinese.
| Flow range | 0–1 L/min |
|---|---|
| Accuracy | ±5 %FS |
| Supply voltage | DC 4.75–5.25 V |
| Output signal | 0–5 V |
| Operating temperature | –10 °C to 60 °C |
| Relative humidity | 35–85 % RH |
| Protection rating | IP40 |
| Housing material | PBT |
| Pressure loss | ≈0.3 kPa |
The sensor measures flow from 0 to 1 L/min.
It operates on a DC supply of 4.75 V to 5.25 V.
The sensor provides an accuracy of ±5 % of full scale.
