This manual provides step‑by‑step instructions for setting up and operating the Haier 25F3A‑T/25T3A‑T color television, including remote control usage, antenna connection, and special features such as the eye‑care backlight (25F3A‑T only). It also covers safety precautions, troubleshooting tips, and technical specifications.
The document is organized into sections on pre‑operation safety, button and interface locations, basic operation, timer power‑off, program reservation, eye‑care backlight installation, technical operations, and a specifications table. This manual is written in Chinese.
| Color System | PAL, AV NTSC 3.58, NTSC 4.43 |
|---|---|
| Screen Size | 25" flat CRT |
| Audio Power | 3 W (no distortion) |
| Power Supply Voltage | 220 V 50 Hz |
| Power Consumption | 120 W |
| Dimensions (mm) | 645 × 532 × 540 |
| Eye‑Care Backlight (25F3A‑T only) | 1 W / 220 V |
Press and hold the numeric key 1 on the remote for about 6 seconds; the TV will begin auto‑searching for channels.
Insert the antenna plug into the rear antenna terminal and then plug the power cord into a 220 V AC outlet.
