The manual of L17L6A-G1 TV includes descriptions of the function of each button, such as power button, mute button, TV/AV button, display button, auto ad button, PC button, PSM button, volume button, menu button, sleep button, ARC button, SSM button, Q.VIEW button, picture button and time button.
The manual provides safety information, including a warning not to open the unit to avoid electric shock. It describes the front‑panel and remote controls, listing buttons such as POWER, MUTE, MENU, SLEEP, ARC, and picture modes like Q.VIEW and AUTO AD.
Technical data are given, including a picture resolution of 1024×768 @ 60 Hz, supported video standards (PAL, NTSC, SECAM), dimensions, weight, and power requirements for each model. This manual is written in Chinese.
| Dimensions (L17L6A-G1) | 395 mm × 210 mm × 405 mm |
|---|---|
| Weight (L17L6A-G1) | 6.3 kg |
| Power Supply (L17L6A-G1) | 12 V / 3.0 A |
| Dimensions (L15L6A-G0) | 445 mm × 210 mm × 395 mm |
| Weight (L15L6A-G0) | 6.5 kg |
| Power Supply (L15L6A-G0) | 12 V / 5.0 A |
| Resolution | 1024 × 768 @ 60 Hz |
The manual warns of a risk of electric shock and instructs not to open the unit.
The unit measures 445 mm × 210 mm × 395 mm and weighs 6.5 kg.
