The ThinkServer 1160 is a single‑CPU, entry‑level server offering RAID functionality, Intel Pentium III processing, and up to 512 MB of memory. It targets small‑ to medium‑size networks in education, business, and government environments.
This manual covers server overview, system installation, BIOS configuration, IDE RAID hardware, FastBuild settings, operating‑system installation, FastCheck monitoring tools, and a detailed FAQ with warranty and service information. This manual is written in Chinese.
| CPU | Intel Pentium III FC‑PGA 800/866/933 MHz |
|---|---|
| Cache | 256 KB L2 cache |
| Maximum Memory | 512 MB PC‑133 (3 DIMM slots) |
| Chipset | Intel 815SE |
| Front‑Side Bus | 100 MHz / 133 MHz |
| IDE Controller | ATA 66/100 |
| RAID Controller | FastTrak66 IDE RAID card (RAID 0, 1, 0+1) |
| Expansion Slots | 6 PCI slots, 1 AGP slot |
| Hard‑Drive Bays | 4 internal bays |
| Optical Drive | 40× IDE CD‑ROM |
| Network Interface | 10/100 Mbps auto‑negotiating Ethernet |
| Dimensions | 419 mm × 183 mm × 493 mm |
| Operating Temperature | -35 °C to +35 °C |
No. The FastTrack66 card does not support dynamic capacity or configuration changes.
No, they can be different, but the controller will truncate larger drives to match the smallest capacity.
No. The controller and operating‑system drivers handle the disks without BIOS configuration.
