The 万全 2400C server is a department-level product of Lenovo servers, supporting two Intel Pentium III FC-PGA processors and a 133MHz system front-end bus. It can be used as a file server in the internal Intranet network of small and medium-sized enterprises and government offices to meet the needs of small-scale network applications with dozens of nodes.
This manual provides an overview of the Lenovo ThinkServer 2400C, describing its hardware architecture, supported CPUs, memory capacity, and I/O interfaces. It also lists the operating systems that can be installed, such as Windows NT/2000, Novell NetWare, SCO OpenServer, RedHat Linux and Solaris.
Detailed installation instructions are included, covering chassis handling, safety precautions, component placement, EMI shielding, and wiring. Troubleshooting tips for common hardware and SCSI issues are provided at the end of the document. This manual is written in Chinese.
| CPU | Intel Pentium III 800 MHz – 1 GHz |
|---|---|
| Cache | 256 KB |
| SMP Support | Dual‑CPU |
| Memory | Up to 4 GB PC133 Registered ECC SDRAM |
| PCI Slots | 1 × 32‑bit/33 MHz, 1 × 32‑bit/66 MHz |
| SCSI Controller | Ultra 160 SCSI (1 × Ultra 160) |
| IDE Interface | Ultra DMA/33 |
| CD‑ROM | 40/48 × speed IDE |
| Power Supply | 300 W, 220 V 30 Hz |
| Operating Temperature | 10 °C – 35 °C |
| Dimensions | 430 mm × 220 mm × 650 mm (H × W × D) |
The server supports Intel Pentium III processors ranging from 800 MHz to 1 GHz and can operate with two CPUs in SMP mode.
It can accommodate up to 4 GB of PC133 Registered ECC SDRAM using four DIMM slots.
The server is compatible with Windows NT/2000, Novell NetWare, SCO OpenServer, SCO UnixWare, RedHat Linux and Solaris.
