This is a user manual for Little Swan Q609B washing machine, which introduces the machine's operation panel instructions, washing water consumption, abnormal working state handling, water level selection, time reservation and washing program introduction.
This guide explains the control panel functions, water‑level selection, washing programs and how to set timers or lock keys. It also provides troubleshooting steps for common error codes such as E1, E3 and E4.
The document lists the machine’s technical specifications, including voltage, power consumption, capacity and dimensions, and describes the step‑by‑step washing process from connecting water and power to starting a cycle. This manual is written in Chinese.
| Rated Voltage | 220V~ |
|---|---|
| Rated Frequency | 50Hz |
| Rated Input Power | 400W |
| Washing/Spinning Capacity | 6.0 kg |
| Weight | 34 kg |
| Overall Dimensions | 546 × 537 × 920 mm |
| Box Dimensions | 530 × 530 mm |
| Inlet Water Pressure | 0.02‑0.78 MPa |
E1 indicates two unbalanced spin cycles that cannot be auto‑handled; load clothes evenly and close the lid before the machine continues.
The washing machine automatically cuts power about 3 minutes after the wash finishes or after a fault if no key is pressed.
The drum‑clean program cleans the washing tub using water level 7 and a single rinse cycle.
