ASRock N68-GS / N68-S Motherboard is a ATX motherboard designed for mid-range gamers. It supports LGA1156 socket and Intel Core i3 / i5 / i7 processors. The motherboard has 2 DDR3 DIMM slots that support dual-channel memory technology, and can support up to 16GB of memory. The motherboard also has 4 SATA 3.0 ports that support RAID 0/1/5/10 arrays.
This manual covers the ASRock N68-GS / N68-S motherboard, presenting its key features and component identification. It includes the model designation and trademark information for reference.
The document lists the SATA ports and their corresponding motherboard connectors, helping users to correctly attach storage devices. Basic layout diagrams and port numbers are provided for quick installation.
| SATA Ports | SATAII_1 (Port 1.0), SATAII_2 (Port 1.1), SATAII_3 (Port 2.0), SATAII_4 (Port 2.1) |
|---|
The motherboard provides four SATA ports: SATAII_1 (Port 1.0), SATAII_2 (Port 1.1), SATAII_3 (Port 2.0), and SATAII_4 (Port 2.1).
The manual titles each page with "ASRock N68-GS / N68-S Motherboard" indicating the model.
