The 54600-Series oscilloscopes from Agilent cover a range of bandwidths from 60 MHz to 500 MHz and provide up to 2 GSa/s sampling rates. They feature MegaZoom deep memory (4 MB‑8 MB) and a high‑definition display that together enable long‑duration captures without sacrificing resolution.
These mixed‑signal scopes offer flexible triggering (CAN, I2C, LIN, USB, SPI) and standard connectivity via parallel and RS‑232 ports, with an optional GPIB module for faster data transfer. The series includes 2‑channel, 4‑channel, and 2 + 16‑channel MSO models, each suited to analog, digital, or mixed‑signal applications.
| Bandwidth | 60 MHz – 500 MHz |
|---|---|
| Maximum Sample Rate | 2 GSa/s |
| Deep Memory (MegaZoom) | 4 MB – 8 MB standard |
| Channel Configurations | 2‑channel, 4‑channel, 2 + 16‑channel MSO |
| Standard Interfaces | Parallel, RS‑232 |
| Optional Interface | GPIB module |
The series covers bandwidths from 60 MHz up to 500 MHz.
Each scope includes 4 MB to 8 MB of MegaZoom deep memory as standard.
Parallel and RS‑232 ports are standard, and a GPIB interface module can be added.
