The 6680A Series is a 5000-watt dc power supply that has exceptional, proven reliability, making it ideal for manufacturing testing and long-term burn-in
The 6680A Series is a 5000 W single‑output DC power supply designed for manufacturing test and long‑term burn‑in applications. It offers front‑panel and SCPI‑based GPIB programming, analog control for noisy environments, and selectable compensation for inductive loads.
Key specifications include voltage ranges from 0‑40 V, current up to 875 A, programming accuracy of ±0.04 % + 5 mV, ripple and noise as low as 1.0 mV rms, and a compact rack‑mountable size of 425.5 mm × 221.5 mm × 674.7 mm. Optional accessories such as rack‑mount kits and replacement fuses are also listed.
| Maximum Power | 5000 W |
|---|---|
| Maximum Output Current | 875 A (model 6680A) |
| Programming Accuracy (Voltage) | ±0.04 % + 5 mV |
| Transient Response Time | < 900 µs to recover within 150 mV |
| Physical Size (W × H × D) | 425.5 mm × 221.5 mm × 674.7 mm |
| Net Weight | 51.3 kg |
Each unit provides a single output.
Model 6680A can deliver up to 875 A.
The unit measures 425.5 mm × 221.5 mm × 674.7 mm.
