This is the user manual for Philips digital AV receiver, introducing the product's features, characteristics, and usage methods
This manual provides safety guidelines, product overview, and step‑by‑step instructions for setting up the Philips HT‑R3465 digital AV receiver. It explains how to place the unit, connect speakers, antennas, power and other devices, and register the product online.
The guide also details playback options, sound‑adjustment features, preset sound modes, and includes a specifications table, troubleshooting tips, and a glossary of terms used throughout the document. This manual is written in Chinese.
| Total output power | 600 W |
|---|---|
| Frequency response (audio) | 150 Hz ~ 18 kHz ±3 dB |
| Signal‑to‑noise ratio (audio) | > 60 dB (A‑weighted) |
| Power supply | 110‑127 V / 220‑240 V, 50‑60 Hz |
| Power consumption | 100 W |
| Dimensions (W×H×D) | 435 mm × 58 mm × 360 mm |
| Weight | 3.2 kg |
| Speaker impedance | 6 Ω (center), 3 Ω (front/rear) |
Make sure the audio cables are properly connected and select the correct input source (e.g., DI/AUX or MP3 LINK) on the receiver.
Press the AUDIO SYNC button, then use the VOL + / ‑ buttons to set the desired delay time.
