The DES-3028/52 series is an entry-level network management switch from Huawei. The switch features PoE power, four Gigabit uplink combo ports, high port density, granular bandwidth control and extensive network management functions. It is a full-featured and cost-effective solution for businesses.
The DES-3028/52 series are managed Layer 2 Fast Ethernet switches offering 24 or 48 Fast Ethernet ports with optional PoE, four Gigabit uplink combo ports, and extensive security and traffic‑control functions. They provide rich L2 features such as VLAN stacking, link aggregation, QoS, and advanced ACLs, making them suitable for entry‑level network deployments.
Management is supported via a web‑based GUI, CLI, SNMP, RADIUS/TACACS+, and D‑View 6.0 network management system. Additional capabilities include cable diagnostics, DHCP snooping, IGMP/MLD snooping, and D‑Link Single IP Management for centralized configuration of multiple devices.
| Port Count | 24 or 48 Fast Ethernet ports |
|---|---|
| PoE Support | 802.3af PoE on 10/100BASE‑TX ports |
| Uplink Ports | 2×10/100/1000BASE‑T + 2×Combo 10/100/1000BASE‑T/SFP |
| Switching Capacity | 12.8 Gbps (24‑port) / 17.6 Gbps (48‑port) |
| Forwarding Rate | 9.5 Mpps (24‑port) / 13.1 Mpps (48‑port) |
| Power Input | 100‑240 VAC, 50‑60 Hz |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
It supports 802.3af Power over Ethernet on the 10/100BASE‑TX ports.
The switch provides a 4 K VLAN group capacity.
The 48‑port model has a switching capacity of 17.6 Gbps.
