PT-BX30NT / BX21 / BX11 are three portable LCD projectors launched by Panasonic. They have 0.9W low standby power, reliable dustproof design, convenient and flexible wireless / wired network functions, and more basic functions and more convenient functions.
This manual covers the Panasonic PT‑BX30NT, PT‑BX21 and PT‑BX11 LCD projectors, detailing safety precautions, technical specifications, and operating procedures. It includes information on projection size, throw distance, brightness, contrast, and power consumption.
The guide also explains wireless and wired network functions (PT‑BX30NT only), remote monitoring, multi‑screen projection, and maintenance features such as dust‑proof design and lamp replacement. Installation steps, quick start, and troubleshooting tips are provided. This manual is written in Chinese.
| Brightness | 3500 lm / 3200 lm / 3000 lm |
|---|---|
| Lamp Power | 220W (lamp life 3000 h) |
| Standby Power | 0.9 W (eco mode) |
| Weight | ≈2.96 kg |
| Dimensions (W×H×D) | 368 mm × 88 mm × 233 mm |
| Projection Size | 33‑200 inches (4:3) |
The projector uses 0.9 W in eco‑mode standby.
Up to 16 computers can be projected at the same time.
The lamp should be replaced after about 3000 hours of use.
Yes, the PT‑BX30NT model includes wireless LAN for presentations.
