AW-CB400L is a replacement for AW-RP400, AW-PH400 and AW-RC400, and has a resolution of 1000 ROP and supports D-SUB 15 interface.
This manual covers safety precautions, proper handling, and environmental requirements for the AW-CB400L camcorder controller. It explains how to avoid hazards, protect the device from liquid exposure, and ensure correct grounding during installation.
The document details the controller’s parts and functions, front and rear panel layouts, wiring connections, mounting procedures, and how to operate the controller with up to five cameras. It also includes information on power supply, cable length limits, and interface panel positioning. This manual is written in Japanese.
| Operating temperature range | -10 °C to +45 °C |
|---|---|
| Maximum number of cameras | 5 |
| Maximum cable length | 1000 m |
| Power input | 12 V DC |
| Mounting screw size | M4 × 8 mm |
It can be used in environments from -10 °C up to +45 °C.
The controller can control up to five cameras simultaneously.
The cable length can be extended up to 1000 meters.
