This document describes safety precautions for Outdoor Pan/Tilt Head AW-PH650L.
This manual covers safety precautions, disposal information, and general usage guidelines for the Panasonic AW-PH650L outdoor pan/tilt head. It explains the unit's IPX4 waterproof rating, internal heater and fan, and the required CR2032 battery.
Detailed installation instructions are provided for mounting the pan/tilt head and the AC adapter, including bolt sizes, washer usage, and anti‑fall wire requirements. The guide also lists supplied accessories, cable specifications, limiter settings, and procedures for replacing consumable parts such as the ventilating fan.
| Upward rotation angle | 50° |
|---|---|
| Downward rotation angle | 95° |
| Horizontal rotation angle | 320° |
| Maximum load (excluding housing) | 10 kg |
| IP protection rating | IPX4 |
| Operating temperature range | -20 °C to 45 °C |
| Battery type | CR2032 (manganese‑dioxide lithium) |
| Ventilating fan replacement interval | ≈40,000 hours |
| Power cable length (supplied) | 30 m |
| Cable requirement | Water‑proof connecting cables |
The unit can bear up to 10 kg of load, not counting the housing.
It meets the IPX4 water‑proof protection standard.
