GA-X79-UD5 is a motherboard product launched by Gigabyte Technology Co., Ltd. It has high performance, supports quad-channel memory mode, and supports AMD CrossFireX™/NVIDIA SLI system.
This manual explains how to install and configure the Gigabyte GA‑X79‑UD5 motherboard. It covers safety precautions, mounting, CPU and memory installation, and connector descriptions.
The document also details BIOS features, power‑management options, peripheral settings, and troubleshooting information, with tables of specifications for the chipset, memory, storage, audio, and networking components. This manual is written in Chinese.
| CPU Socket | LGA2011 |
|---|---|
| Chipset | Intel X79 |
| Supported Memory | DDR3 2133/1866/1600/1333/1066 MHz, up to 64 GB |
| Audio Codec | Realtek ALC898 |
| LAN | Intel GbE LAN (10/100/1000 Mbit) |
| SATA Ports | 6 Gb/s SATA (SATA3) and 3 Gb/s SATA (SATA2) |
| PCI Express Slots | PCI Express x16, x8, x1 |
The board uses an LGA2011 socket for compatible processors.
The motherboard provides six SATA 6 Gb/s (SATA3) ports.
It includes the Realtek ALC898 high‑definition audio codec.
DDR3 memory up to 2133 MHz (also supports 1866, 1600, 1333, 1066 MHz).
