This document is the user manual for the ASUS P3W-E motherboard, providing instructions and precautions for its usage.
This manual covers the features and specifications of the ASUS P3W-E motherboard, including supported CPUs, chipset, memory, expansion slots, and integrated graphics. It also explains the hardware installation steps, BIOS settings, and software installation procedures.
Additional sections provide troubleshooting guidance, BIOS update instructions, and details on optional accessories such as the PCI‑L101 Ethernet card and S370 CPU conversion cards. This manual is written in Chinese.
| Supported CPUs | Intel Pentium III (≥450 MHz), Pentium II (233‑450 MHz), Celeron (≥266 MHz) |
|---|---|
| Chipset | Intel 810e |
| PCI slots | Five PCI slots (alternative configuration with six PCI slots) |
| ISA slots | Two ISA slots (alternative configuration with one ISA slot) |
| IDE interface speed | UltraDMA/66 (66 MB/s), UltraDMA/33 (33 MB/s), PIO Mode 4 (17 MB/s) |
| JumperFree BIOS mode | Allows CPU Vcore, multiplier and bus frequency adjustment via BIOS |
It supports Intel Pentium III processors at 450 MHz or higher, Pentium II processors from 233 MHz to 450 MHz, and Celeron processors at 266 MHz or higher.
The motherboard provides five PCI slots (with an alternative configuration offering six PCI slots) and two ISA slots (or one ISA slot in the alternative layout).
