User manual of P5L-MX/IPAT motherboard, introducing the features, installation steps, BIOS settings and other content.
The manual begins with safety guidelines and an overview of the P5L-MX/IPAT motherboard, describing its layout, connector locations, and key features. It then walks the user through hardware installation, including CPU, memory, and peripheral components, with detailed diagrams and part numbers.
Later sections cover BIOS setup, chipset configuration, and advanced options such as Hyper‑Threading, SpeedStep, and power management. The document also lists supported drivers, provides troubleshooting tips, and points to additional resources on the ASUS website. This manual is written in Chinese.
| CPU Socket | LGA775 |
|---|---|
| Supported CPU Feature | Hyper‑Threading Technology |
| Memory Type | DDR2 |
| PCI Express Slots | x16, x1 |
| PCI Express Slots | x1 |
| On‑Board LAN | Present |
| Super I/O Controller | Present |
| BIOS Configuration Menu | CPU Configuration, Memory Information, Advanced Settings |
| Memory Information Menu | Provides details on installed memory |
The P5L‑MX/IPAT supports DDR2 memory modules, as listed in the DDR2 qualified vendor list.
Run the AFUDOS command with the appropriate ROM file (e.g., afudos /i P5L-MX/IPAT.ROM) from DOS or a bootable environment.
