This document is the product manual for Bosch Rexroth VT 11007 and VT 11016 type 1X series modular electronic amplifiers. This module is used to control non-electric feedback proportional pressure reducing valves, and has differential input, 2 pulse width modulation output terminals, step function generator, 2 switch signal output, short circuit protection and LED display lamp features.
The document provides an overview of the VT 11007 and VT 11016 simulation amplifier modules, describing their function, key features and typical applications in hydraulic systems. It includes safety notices, installation guidelines and wiring diagrams to ensure correct integration.
Technical data such as electrical parameters, dimensions, weight, IP rating and operating temperature ranges are listed, along with characteristic curves for both model variants. The manual also outlines recommended mounting methods according to DIN standards and provides troubleshooting tips. This manual is written in Chinese.
| Supply Voltage Range | 0 V – 16 V |
|---|---|
| Typical Operating Voltage | 12 VDC ±40% |
| Maximum Current | 21 A |
| Dimensions (W×H×D) | 40 mm × 79 mm × 85.5 mm |
| Weight | 0.16 kg |
| Operating Temperature Range | -25 °C to +70 °C |
The modules operate from 0 V up to 16 V, with a typical operating voltage of 12 VDC ±40%.
Each module measures 40 mm × 79 mm × 85.5 mm and weighs about 0.16 kg.
