This document introduces the specifications and technical data of the 60CB series AC servo motor, including power, torque, speed, winding resistance, etc.
The 60CB series AC servo motors from Hollysys are small‑volume, high‑precision, high‑speed devices designed for motion‑control applications. They offer rated powers from 200 W to 600 W, rated torques up to 1.91 N·m and a maximum speed of 3600 rpm.
The document lists detailed technical data, including encoder resolution, brake wiring, compatible drivers (MS0020C/ MS0020A/ GS0020A, etc.), and installation precautions such as brake control voltage and connector pin assignments. It also provides the motor’s physical dimensions, weight, and environmental limits. This manual is written in Chinese.
| Rated output power | 200 W / 400 W / 600 W |
|---|---|
| Rated torque | 0.64 N·m / 1.27 N·m / 1.91 N·m |
| Rated speed | 3000 rpm |
| Maximum speed | 3600 rpm |
| Weight | 1.0 kg / 1.4 kg / 1.8 kg |
| Encoder resolution | 2500 pulses/rev |
| Insulation resistance | 100 MΩ at 500 VDC |
| Operating temperature range | -20 °C to +50 °C |
Connect the brake control line to a 24 VDC power source that can supply at least 2 A.
The 60CB series can be used with drivers MS0020C, MS0020A, GS0020A, MS0040C, MS0040A, GS0040A, MS0075C, MS0075A, and GS0075A.
The encoder provides 2500 pulses per revolution.
