The Okolene line wire from Shanghai Laitao Electrical Wire & Cable Co., Ltd. is a high-strength cable designed for use on overhead signal and power circuits installed on insulators. It features solid or stranded hard drawn bare copper or solid Copperweld conductors and Okolene (polyethylene) insulation from AREMA Signal Manual Part 10.3.21. This wire meets all requirements of AREMA Signal Manual Part 10.3.10 and has excellent electrical properties, mechanical ruggedness, and moisture, heat, and weather resistance.
Okonite's Okolene Line Wire is a polyethylene‑insulated copper conductor designed for overhead signal and conduit installations. The wire is offered in sizes from #12 AWG to #4 AWG with a covering thickness of 27/64" and an insulation thickness of 2/64".
The product data includes conductor standards (ASTM B‑3, B‑8, B‑227), insulation compliance with AREMA Signal Manual Part 10.3.21, minimum order quantity of 5,000 ft, and standard packaging options such as 12 AWG and #10 AWG coils or non‑retrievable reels.
| Insulation Material | Okolene (polyethylene) per AREMA Signal Manual Part 10.3.21 |
|---|---|
| Insulation Thickness | 2/64" |
| Covering Thickness | 27/64" for #12 AWG through #4 AWG |
| Minimum Order Quantity | 5,000 ft |
The wire uses Okolene polyethylene insulation, complying with AREMA Signal Manual Part 10.3.21.
The minimum manufacturing quantity is 5,000 feet.
Standard packages include 12 AWG and #10 AWG coils (1,000 coils) and non‑retrievable reels.
