Mitsubishi general inverter built-in option user manual, mainly introduces the use precautions of inverter, including safety precautions, transportation and installation precautions, trial operation precautions, operating precautions, maintenance, inspection and component replacement precautions, scrap after treatment precautions, general precautions
This manual covers safety precautions, installation procedures, and wiring requirements for the Mitsubishi FR‑A7AP general frequency converter. It explains the three control modes—directional control, encoder feedback control, and vector control—along with the associated parameter lists.
Detailed specifications such as maximum speed, torque control range, and accuracy are listed, and the document includes wiring diagrams, connector pinouts, and recommended cable types for reliable operation. This manual is written in Chinese.
| Maximum speed | 120 Hz |
|---|---|
| Speed response | 300 rad/s |
| Torque control range | 1:50 |
| Absolute torque accuracy | ±10 % |
Do not open the front cover while the unit is powered, ensure the converter is grounded, and only qualified personnel should perform installation or maintenance.
Use shielded twisted‑pair cable of at least 0.2 mm², follow the recommended wiring diagrams, and keep cables away from noise sources.
The converter can operate up to a maximum speed of 120 Hz.
The torque control range is set to 1:50.
