TA58MS00F is a variable output voltage regulator with an output voltage range of 2.475 V to 24 V and a maximum output current of 500mA. The device has overcurrent protection, overtemperature protection, 60 V load dump and overvoltage protection functions.
The TA58MS00F is a compact, surface‑mount linear regulator offering a maximum output current of 500 mA. Output voltage can be set between 2.475 V and 24 V using external resistors, and the device includes an enable (ON/OFF) pin for standby operation, making it suitable for battery‑powered and low‑power equipment.
The regulator provides over‑current, over‑temperature, overload‑dump (60 V) and over‑voltage protection. Typical application circuits and pin‑out details are provided, along with absolute maximum ratings and electrical characteristics for reliable design integration. This manual is written in Japanese.
| Maximum output current | 500 mA |
|---|---|
| Adjustable output voltage range | 2.475 V – 24 V |
| Standby (output off) current | 1.0 nA (max) |
| Low bias current | 2.2 mA (typical) |
| Protection functions | Over‑current, over‑temperature, 60 V load‑dump, over‑voltage |
The device can deliver up to 500 mA of output current.
The standby current is specified as 1.0 nA (maximum).
It includes over‑current, over‑temperature, 60 V load‑dump and over‑voltage protection.
The regulator is supplied in an HSIP5‑P‑1.27B 5‑pin surface‑mount package.
