Cisco Small Business Smart Switches are cost-effective switching solutions ideal for small businesses or workgroups within larger organizations. These high-speed switches offer entry-level management features, avoiding the higher costs and complexity of a fully managed Layer-2 switch.
The Cisco SLM2005 Smart Switch is a cost‑effective, 5‑port Gigabit Ethernet switch designed for small‑business environments and workgroups. It supports both PoE (IEEE 802.3af) on port 1 and an external power supply, allowing flexible installation in locations without a wall outlet.
The datasheet details the switch’s technical specifications, including non‑blocking 10 Gbit/s switching capacity, 7.44 Mpps forwarding rate, VLAN and QoS features, and environmental ratings. It also lists required accessories, warranty information, and supported web‑based management tools. This manual is written in German.
| Forwarding rate | 7.44 Mpps |
|---|---|
| VLAN support | 16 active VLANs (up to 4096) |
| PoE support | IEEE 802.3af PD on port 1 |
| Dimensions | 130 × 28.5 × 130 mm (5.12 × 1.12 × 5.12 in) |
| Weight | 0.382 kg (0.84 lb) |
| Operating temperature | 0 °C to 40 °C |
The switch provides five 10/100/1000‑Mbps (Gigabit) Ethernet ports.
