Cisco 880 Series Integrated Services Routers are fixed configuration routers that provide a collaborative business solution for securing data communications for small businesses and remote workers of large enterprises.
The Cisco 880 Series integrates broadband Internet access, security and wireless services in a single device for small‑office, branch‑office and remote‑worker environments. It supports firewall, content filtering, VPN, QoS and optional 802.11n WLAN, with centralized management via Cisco Configuration Professional.
The manual provides detailed hardware specifications (DRAM, flash, ports, PoE), software feature sets (routing, security, advanced IP services), ordering information, licensing options and service support contacts, enabling IT managers to deploy and manage the router efficiently. This manual is written in Chinese.
| Default DRAM | 256 MB |
|---|---|
| Maximum DRAM | 768 MB |
| Default Flash | 128 MB |
| WAN interfaces | Fast Ethernet, G.SHDSL, 3G, ISDN |
| PoE ports | 2 ports supporting 802.3af PoE |
| USB port | 1 × USB 1.1 |
| Wireless standard | 802.11n (draft v2.0) with 2x3 MIMO |
It supports Fast Ethernet, G.SHDSL (2‑line and 4‑line), ISDN backup, and 3G (CDMA‑EVDO, GSM/UMTS) connections.
Two ports support 802.3af PoE for powering IP phones or external access points.
The default DRAM is 256 MB.
The router includes an integrated 802.11n draft v2.0 access point, compatible with 802.11b/g, and supports MIMO 2×3.
