EPC-3101 is a PC/104 compatible MiniISA industrial control board developed by Guangzhou ZHIYUAN Electronics CO., LTD. It is based on 32-bit ARM LPC2460 processor. EPC-3101 features rich resources, large memory capacity, complete interfaces, low power consumption and high reliability. It comes with μC/OS-II real-time operating system, TCP/IP, CAN-bus, Modbus, USB2.0Host, FAT32 file system, and supports remote firmware upgrade. EPC-3101 industrial control board can work stably in a wide temperature range of -40°C ~ +85°C, meeting the requirements of various industrial applications.
The EPC-3101 is a MiniISA‑based industrial control motherboard developed by ZLG. It uses a 32‑bit ARM7 LPC2460 CPU, runs μC/OS‑II, and provides a wide range of interfaces including industrial Ethernet, CAN, RS‑485, USB host, CF card, and MiniISA expansion slots. The board operates reliably from –40 °C to +85 °C and supports remote firmware upgrades.
Technical data include 32 MB SDRAM, 2 MB NOR Flash, 256 MB NAND Flash, 8‑channel A/D, 8‑channel digital I/O, and a hardware watchdog. Mechanical dimensions follow the PC/104 standard (90 mm × 96 mm) and the board includes isolation for CAN and RS‑485 interfaces. This manual is written in Chinese.
| CPU | LPC2460 (32‑bit ARM7) |
|---|---|
| Operating Temperature | -40 °C ~ +85 °C |
| SDRAM | 32 MB |
| Ethernet Interface | 1 × 10/100 M industrial Ethernet |
| CAN Interface | 1 × industrial CAN (isolated) |
| MiniISA Bus | Supported |
| Real‑time OS | μC/OS‑II |
The board works reliably from –40 °C to +85 °C.
Yes, the board supports the MiniISA bus for attaching compatible modules.
μC/OS‑II is pre‑installed on the EPC-3101.
