Guangzhou ZLG EPC-3100 EPC3000 series MiniISA IPC motherboard Manual
The EPC-3100 is a MiniISA‑based industrial control motherboard developed by ZLG. It features a 32‑bit ARM7 LPC2460 CPU, extensive I/O, Ethernet, CAN, USB host, and on‑board storage, and operates reliably from –40 °C to +85 °C.
The document provides detailed hardware architecture, electrical parameters, mechanical dimensions, and ordering information, making it a comprehensive reference for engineers designing embedded control systems. This manual is written in Chinese.
ZLG EPC3000 specifications
| CPU | LPC2460 32‑bit ARM7 |
|---|---|
| Operating Temperature | -40 °C ~ +85 °C |
| Power Supply Voltage | 4.75 V – 5.25 V |
| Power Consumption | 193.7 mA (typical) |
| CAN Interfaces | 2 ports (industrial‑grade) |
| Ethernet | 10/100 M (industrial‑grade) |
| USB Host | USB2.0 |
Source: Guangzhou ZLG EPC-3100 EPC3000 series MiniISA IPC motherboard Manual
All ZLG EPC3000 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What temperature range can the EPC-3100 operate in?
The board works reliably from –40 °C to +85 °C.
From: Guangzhou ZLG EPC-3100 EPC3000 series MiniISA IPC motherboard Manual
Which CPU is used in the EPC-3100 motherboard?
It uses a 32‑bit ARM7 LPC2460 processor.
From: Guangzhou ZLG EPC-3100 EPC3000 series MiniISA IPC motherboard Manual
What temperature range can the EPC-3101 operate in?
The board works reliably from –40 °C to +85 °C.
From: Guangzhou ZLG EPC-3101 EPC3000 series MiniISA IPC motherboard Manual
Does the EPC-3101 support the MiniISA expansion bus?
Yes, the board supports the MiniISA bus for attaching compatible modules.
From: Guangzhou ZLG EPC-3101 EPC3000 series MiniISA IPC motherboard Manual
