Key facts
- Manuals
- 99
- Models
- 1
- Categories
- 5
- Languages
- ZH
- Last added
- 2026-10-01
ZLG models by category
Featured ZLG manuals
ZLG V2.XX CANTest Software User Manual
This manual provides step‑by‑step instructions for installing the CANTest software, including copying the controlcan.dll file from the ZLG software folder on the CD to the program’s installation directory. It also covers device selection, channel configuration and language settings.
The guide details the main features of the software such as data reception with filter settings, data transmission in basic and advanced modes, real‑time saving of logs to TXT or CSV files, and core DBC support for automotive protocols. Additional functions include device information, error frame display, and customizable frame ID display formats. This manual is written in Chinese.
Covers: Software Installation · Software Settings · Data Reception · Data Transmission · DBC Core Function · Other Functions
ZLG ZLG116N32A 32-bit Microcontroller Datasheet
The ZLG116N32A microcontroller uses a high‑performance ARM® Cortex®‑M0 core and integrates up to 64 KB of flash program memory, 8 KB of SRAM, a 12‑bit ADC, several timers, and a set of communication interfaces (2 UART, 1 I2C, 1 SPI). It operates from 2.0 V to 5.5 V and supports various low‑power modes for energy‑efficient applications.
Typical applications include industrial instrumentation, IoT devices, and medical equipment. Ordering information and mechanical details are provided, and the device is supplied in a QFN32 package. This manual is written in Chinese.
Covers: 概述 · 产品特性 · 规格说明 · 器件对比 · 引脚定义 · 电气特性
ZLG LPC2478 ucLinux Module User Manual
This manual provides an overview of the LPC2478 ucLinux module, its supported interfaces, and the main functions available through the TKStudio external tool. It explains how the module integrates the LPC2478 MCU with ucLinux and how to interact with the device via the provided software.
The document is organized into sections covering function overview, detailed operation instructions, log handling, external interface connections, example programs, and a disclaimer. Contact information for technical support and email addresses for various tools (CAN‑bus, MiniARM, Ethernet, etc.) are also listed. This manual is written in Chinese.
Covers: Function Overview · Main Features · Operation Instructions · Log Operations · External Interfaces · Example Programs
ZLG PCM-8308BS PC/104 High-Speed Analog Input Card Product Data Manual
The PCM-8308BS is an intelligent PC/104 analog input card designed for industrial signal acquisition. It offers a 200 kHz sampling rate, 16‑bit resolution, and configurable input ranges (±10 V, ±5 V, 0‑10 V, 0‑5 V) across 16 single‑ended or 8 differential channels, with automatic channel calibration and over‑voltage protection.
Technical specifications include a 2 K‑sample FIFO buffer, 20 MΩ input impedance, 30 V max input protection, operating temperature from –25 °C to 185 °C, and power consumption of 270 mA typical at +5 V. The card conforms to the PC/104 16‑bit mechanical dimensions (90 mm × 96 mm). This manual is written in Chinese.
Covers: PCM-8308BS Introduction · Function Overview · Electrical Parameters · Static Parameters · Pin Information · Block Diagram
Latest ZLG manuals
ZLG V2.XX CANTest Software User Manual
User Manual 12 pages · 1.2 MB · ZHThe ZLG CANTest V2.XX software user manual explains installation, configuration, and how to use data receive, send, DBC parsing and other functions.
ZLG ZLG116N32A 32-bit Microcontroller Datasheet
Datasheet 53 pages · 1.5 MB · ZHThe ZLG116N32A is a 32‑bit ARM Cortex‑M0 microcontroller featuring up to 64 KB flash, 8 KB SRAM, multiple timers, ADC, UART, I2C, SPI and low‑power modes.
Guangzhou ZLG ZYT-82 RS-232 Isolators Manual
ZYT-82 RS-232 isolator is a serial optical isolator produced by Guangzhou Zhiyuan Electronic Co., Ltd. It adopts the unique serial port power theft and optical isolation technology, which can effectively protect RS-232 serial port devices, avoid ground loop voltage, surge, induced lightning strike, static electricity, hot plug and other harsh environments damage to the device.
Guangzhou ZLG ZY_UHBD-5W Wide input voltage isolation regulator single output series handbook
ZY_UHBD-5W is a wide-voltage input isolation power supply series module developed by Guangzhou Zhiyuan Electronics. It has high conversion efficiency, good high and low temperature characteristics, strong capacitive load capacity, and short circuit protection functions. International standard pin-out, UL94-V0 flame-retardant package, natural cooling, no need for external heat sinks, no need for external components can be used directly, and can be directly welded on the PCB board. Simple connection, it is your ideal front-stage power solution.
ZLG LPC2478 ucLinux Module User Manual
User Manual 14 pages · 533 KB · ZHThe ZLG LPC2478 ucLinux module manual describes the interface, main functions, operation steps, and example programs for using the LPC2478 with ucLinux.
ZLG PCM-8308BS PC/104 High-Speed Analog Input Card Product Data Manual
Datasheet 13 pages · 418 KB · ZHThe ZLG PCM-8308BS is a PC/104 high‑speed analog input card with 16‑bit resolution, 200 kHz sampling, up to 16 single‑ended or 8 differential channels, and…
ZLG RSM-3402 Data Sheet
User Manual 14 pages · 714 KB · ZHThe ZLG RSM-3402 data acquisition module manual provides specifications, wiring, and installation instructions.
Guangzhou ZLG EPCM-2644 EPCM2000 series date collect IPC motherboard handbook
Datasheet 14 pages · 1.2 MB · ZHTechnical data sheet for the ZLG EPCM-2644 industrial control motherboard, detailing hardware resources, interfaces and specifications.
Guangzhou ZLG EPCM-2944 EPCM2000 series date collect IPC motherboard handbook
Datasheet 15 pages · 1023 KB · ZHThe EPCM-2944 is a ZLG data‑acquisition industrial control board with 8 analog inputs, 8 digital I/O, Ethernet, CAN, RS‑232/485, CF card and MiniISA expansion.
Guangzhou ZLG ZY_WRAD-3W Wide input voltage isolation regulator double output series handbook
ZLG ZY_WRBCS-2W Wide Input Voltage Isolation Regulator Series Handbook
Datasheet 13 pages · 415 KB · ZHThe ZLG ZY_WRBCS-2W series handbook provides specifications, mechanical dimensions, and performance curves for the wide input voltage isolation regulator.
ZLG ZY_WHBD-3W Wide Input Voltage Isolation Regulator Handbook
User Manual 11 pages · 320 KB · ZHThe ZLG ZY_WHBD-3W handbook provides specifications, pinout, application circuits, and safety information for the wide‑input voltage isolation regulator series.
ZLG RSM-3802 8-Channel Analog Input Data Acquisition Module Manual
User Manual 13 pages · 418 KB · ZHThe ZLG RSM-3802 manual details features, specifications, installation and operation of the 8‑channel analog input data acquisition module.
ZLG NDAM-3800 Datasheet
Datasheet 15 pages · 1.2 MB · ZHThe ZLG NDAM-3800 is an 8‑channel, 12‑bit analog input module for distributed data acquisition, supporting Ethernet, RS‑485/422/232 and CAN‑bus communication.
Guangzhou ZLG EPCM-2940 EPCM2000 series date collect IPC motherboard handbook
Datasheet 15 pages · 653 KB · ZHTechnical data sheet for the ZLG EPCM-2940 industrial data‑acquisition control board.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Application Note
How to use the product for one specific task, with worked examples.
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in ZLG manuals
How do I install the CANTest software?
Run the CANTest_Setup_V2.XX.exe from the CD and copy the controlcan.dll from the ZLG software folder on the CD into the CANTest installation directory.
How can I filter specific CAN IDs?
Open the filter settings, choose a filter mode (e.g., standard frame single filter), enter the desired ID and confirm to receive only frames with that ID.
What is the operating voltage range of the ZLG116N32A?
It operates from 2.0 V to 5.5 V.
How many UART interfaces does the ZLG116N32A provide?
The device includes two UART interfaces.
What external tool is used with the LPC2478 ucLinux module?
The module is used together with the TKStudio external tool.
How can the log be cleared on the module?
In the log menu you can select the 【清空】 (Clear) option to erase the log.
