Cisco MWR 2941-DC Mobile Wireless Router is a cell site gateway specifically designed to clock, aggregate, and backhaul mixed-generation RAN traffic. The Cisco MWR 2941-DC prioritizes and processes cell-site voice, data, and signaling traffic as part of the Cisco Unified RAN Backhaul solution for reliable transport across an WAN.
The Cisco MWR 2941-DC Mobile Wireless Router is a cell‑site gateway designed to aggregate and backhaul mixed‑generation RAN traffic, supporting various backhaul media such as T1/E1, Ethernet, microwave, WiMAX, and satellite.
The router includes sixteen RJ‑45 T1/E1 ports, four Gigabit Ethernet ports, two SFP ports, a built‑in Layer 2 switch, and a DC‑only power supply rated 20‑60 VDC. It runs Cisco IOS Software with hardware‑accelerated network services and offers extensive timing, security, and management features.
| Processor types | Cisco IOS Software host processor, network processor |
|---|---|
| Flash memory (compact flash) | 128 MB external |
| System memory | 512 MB DRAM (default) |
| Onboard T1/E1 ports | 16 |
| Onboard Ethernet ports | 4 × 100/1000BASE‑T RJ‑45, 2 × 1000BASE‑X SFP |
| DC‑input power (nominal/maximum) | 45 W / 65 W |
| DC‑input voltage rating | 20 to 60 VDC (27 VDC or –48 VDC nominal) |
| Operating temperature | -4 to 140 °F (‑20 to 60 °C) |
| Dimensions (H×W×D) | 1.72 × 17.5 × 12.5 in. |
| Weight (no modules) | 12 lb (5.44 kg) |
It accepts 20 to 60 VDC, with nominal options of 27 VDC or –48 VDC.
The router includes sixteen integrated RJ‑45 T1/E1 ports.
It operates from –4 °F to 140 °F (‑20 °C to 60 °C).
Yes, it supports IPv4/IPv6 dual‑stack operation.
