FP series programmable controller programming manual, introduces basic instructions, interrupt control, communication conditions setting, password setting, interrupt setting, PC-link time setting, MEWTOCOL-COM response control, high-speed counter action mode change, system register modification (No.40~No.47, No.50~57), floating-point real data comparison (start) and floating-point real data comparison (start).
This manual provides the complete programming reference for Panasonic FP series programmable controllers. It includes basic instruction sets, advanced functions, and detailed examples for configuring interrupts, communication parameters, and data conversion.
The document is organized into sections such as Basic Commands, Advanced Commands, Interrupt Control (ICTL), System Communication Settings (SYS1), and specialized functions like PID control and automatic tuning. Each section contains command syntax, usage notes, and sample ladder logic programs. This manual is written in Chinese.
| Supported Models | FP0, FPΣ, FP‑X, FP1, FP‑M |
|---|
Use the ICTL instruction with S1 set to H0002 and S2 set to the desired interval, e.g., K1500 for a 15‑second interval.
Use ICTL with S1 set to H0100 and S2 to the bit pattern of the interrupt to clear, for example HFE to clear INT0.
