The guide begins with safety precautions, warning symbols, and proper handling instructions to ensure safe installation and operation of the MLC 104 series controllers. It emphasizes reading and retaining all safety information before powering the device.
The document then walks the user through hardware connections, front‑panel operation, and detailed software setup using Extron Global Configurator, including driver installation, project creation, email notification configuration, and firmware updates for both the MLC 104 and MLC 104 IP models.
| Power Input | 100‑240 V, 1.0 A max, 50‑60 Hz |
|---|---|
| Audio Input Type | Line‑level mono |
| Audio AUX/MIX Adjustment | -42 dB to +24 dB |
| Control Interfaces | RS‑232 and IR ports |
Read and understand all safety and operating instructions, retain the safety instructions for future reference, and follow all warnings marked on the equipment.
The controller operates from a 100‑240 V AC source, drawing up to 1.0 A at 50‑60 Hz.
