TMS7 ME00070B Error Codes

16 codes from pages 29–30 of the manual

This is the list of fault codes the TMS7 manual gives for the ME00070B TMS7 soft starter. Find your code below and open it for what the manual says about its causes and what to do.

Fault codes from p. 29

CodeWhat it meansPage
0 Shorted SCR p. 29
2 Overcurrent trip p. 29
3 Motor thermistor trip p. 29
4 Current imbalance trip p. 29
5 Supply frequency trip p. 29
6 Phase rotation trip p. 29
7 Stall trip p. 29
8 Power circuit fault p. 29
9 Undercurrent trip p. 29
F Heatsink overtemperature trip p. 29
P Invalid motor connection p. 29
C RS485 communication fault p. 29
E EEPROM read/write failure p. 29
L Out of range FLC p. 29
Y Incorrect main control module. p. 30
U CPU error p. 30

Codes and descriptions are taken from the manufacturer’s manual; page numbers link to the PDF. ManualLib is not affiliated with TMS7. Found a mistake? Report an error.
