Data Delay Devices models by category
Featured Data Delay Devices manuals
Data Delay Devices PDU1016H 4-Bit ECL-Interfaced Programmable Delay Line Datasheet
The PDU1016H-series device is a 4-bit digitally programmable delay line featuring ECL interfacing and buffering. It offers 16 programmable delay steps with monotonic delay-versus-address variation, allowing precise and stable delays. The device fits a 32-pin DIP socket and is available in various packages including DIP and SMD.
Covers: Functional Description · Pin Descriptions · Series Specifications · Application Notes · Address Update · Input Restrictions
Data Delay Devices PDU-1016H Digitally Programmable Delay Units Datasheet
This document describes the PDU-1016H series of Digitally Programmable Delay Units manufactured by Data Delay Devices. These units feature a 4-bit ECL programmable delay line with low propagation delay and buffered inputs and outputs.
The datasheet provides key specifications such as programmed delay tolerance, inherent delay, and power dissipation. It includes a comprehensive truth table listing various part numbers (e.g., PDU-1016H-5 through PDU-1016H-100) with their corresponding incremental delays and total programmed delays.
Covers: Features · Specifications · Test Conditions · Truth Table · Part Numbers
Data Delay Devices DDU-7 Series Digital Delay Units Datasheet
The Data Delay Devices DDU-7 Series consists of completely interfaced Digital Delay Units designed for TTL and DTL applications. These units require no external components and fit into standard 14-pin DIP sockets, achieving board space economy.
Key features include operation over the full military temperature range of -55°C to +125°C with a supply voltage of 4.5 to 5.5 Vdc. The datasheet provides specifications for various models ranging from DDU-7-10 to DDU-7-500, detailing total delay times and tolerances.
Covers: Features · Test Conditions · Specifications · Total Delay Tolerance · Rise-time · Temperature Coefficient
Agilent CP-2002/2003 Micro-GC Control Operation Manual
This document describes the operation of the Star Chromatography Workstation when used with the CP-2002 and CP-2003 Micro-GC. It covers configuring an instrument for data acquisition, building a method, and running samples. The manual explains how to use the Star Toolbar for system control, automation, and viewing chromatograms.
Covers: Getting Started · Star Toolbar · Building Methods · Injecting a Single Sample · Injecting Multiple Samples · Using QuickStart
Latest Data Delay Devices manuals
data delay devices single-in-line Delay lines 1507 handbook
DATA DELAY DEVICES INC MECHANICALLY VARIABLE DELAY LINE (SERIES 1503 1503J) handbook
1509/1509J MECHANICALLY VARIABLE DELAY LINE (SERIES 1509 & 1509J) is a mechanically variable, passive delay line from data delay devices, inc. It features multi-turn adjustment screw, ideal for “Set and Forget” applications, stackable design, 14-pin DIP socket, 20mil x 10mil flat leads, #20 gauge leads, resolution as low as 0.15ns, dielectric breakdown of 50 Vdc, and temperature coefficient of 200 PPM/°C.
DATA DELAY DEVICES INC MECHANICALLY VARIABLE DELAY LINE (SERIES 1503 1503J) handbook(1)
1503/1503J series mechanically variable delay lines are passive delay lines produced by data delay devices, inc., with multiple characteristics, including adjustability, stackability, and high precision.
Data Delay Devices PDU1016H 4-Bit ECL-Interfaced Programmable Delay Line Datasheet
Datasheet 5 pages · 50 KB · ENDatasheet for the Data Delay Devices PDU1016H, a 4-bit digitally programmable delay line with ECL interfacing and 16 delay steps.
Data Delay Devices PDU-1016H Digitally Programmable Delay Units Datasheet
Datasheet 1 pages · 102 KB · ENA datasheet for the Data Delay Devices PDU-1016H series, detailing 4-Bit ECL interfaced programmable delay units with specifications and part numbers.
Data Delay Devices DDU-7 Series Digital Delay Units Datasheet
Datasheet 1 pages · 95 KB · ENTechnical datasheet for the Data Delay Devices DDU-7 Series, a military-type digital delay unit with 10 taps and TTL/DTL interfacing.
Agilent CP-2002/2003 Micro-GC Control Operation Manual
User Manual 72 pages · 1 MB · ENOperation manual for controlling Agilent CP-2002 and CP-2003 Micro-GC instruments using the Star Chromatography Workstation software.
DATA IMAGE GM123210SFSYB-01 LCD Module Specification
This document records the revision history, specifications, and absolute maximum ratings of the GM123210GFAAB-01 product.
CASIO XJ-A135/XJ-A145/XJ-A235/XJ-A245 Data Projector Wireless Function Guide
User Manual 46 pages · 1.3 MB · ENThis guide explains how to establish a wireless LAN connection between CASIO data projectors and computers to project screen contents.
Data Delay Devices 3D7428 Programmable Delay Line Datasheet
Datasheet 7 pages · 192 KB · ENTechnical datasheet for the Series 3D7428 low noise monolithic 8-bit programmable delay line IC, detailing specifications and application notes.
Data Delay Devices 3D7205 Series Monolithic 5-Tap Fixed Delay Line Datasheet
Datasheet 4 pages · 125 KB · ENTechnical datasheet for the Data Delay Devices 3D7205 series, a monolithic 5-tap fixed delay line IC with TTL/CMOS compatibility.
Data Delay Devices DLO31F TTL-Interfaced Gated Delay Line Oscillator Datasheet
Datasheet 4 pages · 61 KB · ENA datasheet for the Data Delay Devices DLO31F, a gated delay line oscillator with frequencies from 2MHz to 40MHz and standard 14-pin DIP packaging.
data delay devices inc. 5-TAP TTL-INTERFACED FIXED DELAY LINE (SERIES DDU4F)
Datasheet 4 pages · 64 KB · ENTechnical datasheet for the DDU4F series, a 5-tap TTL-interfaced fixed delay line with various package options and specifications.
data delay devices MONOLITHIC MANCHESTER DECODER SERIES 3D7502
DATA DELAY DEVICES 1520 DATA SHEET
1520 is a 10-tap DIP/SMD delay line with a delay time of up to 1000ns. It is low-profile and epoxy-encapsulated, and meets or exceeds MIL-D-23859C standards.
- 1
- 2
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Data Delay Devices manuals
What is the formula for the delay of the PDU1016H?
The delay (TDa) depends on the address code (A) according to the formula: TDa = TDp + Tinc * A.
From: Data Delay Devices PDU1016H 4-Bit ECL-Interfaced Programmable Delay Line Datasheet
What is the range of incremental delay for the PDU1016H?
The incremental delay can range from 0.5ns through 100ns, inclusively.
From: Data Delay Devices PDU1016H 4-Bit ECL-Interfaced Programmable Delay Line Datasheet
What is the programmed delay tolerance for the PDU-1016H?
The programmed delay tolerance is either 6% or 1 ns, whichever value is greater.
From: Data Delay Devices PDU-1016H Digitally Programmable Delay Units Datasheet
What are the typical propagation delays from address and enable inputs to output?
The typical address-to-output delay is 3.6 ns, while the enable-to-output delay is 1.7 ns.
From: Data Delay Devices PDU-1016H Digitally Programmable Delay Units Datasheet
What is the temperature range for the DDU-7 series?
The units operate over a full military temperature range of -55°C to +125°C.
From: Data Delay Devices DDU-7 Series Digital Delay Units Datasheet
Are external components required for the DDU-7?
No, there are no external components required as the units are completely interfaced.
From: Data Delay Devices DDU-7 Series Digital Delay Units Datasheet
