This data selector/multiplexer contains full binary decoding to select one-of-eight data sources and features strobe-controlled complementary 3-state outputs. The 3-state outputs can interface with and drive data lines of bus-organized systems. With all but one of the common outputs disabled (at a high-impedance state), the low-impedance of the enable output will drive the bus line to a high or low logic level. Both outputs are controlled by the strobe (G). The outputs are disabled when G is hi
The document details the 74AC11251, an integrated circuit designed to select one of eight data sources using full binary decoding. It features strobe-controlled complementary 3-state outputs that allow interfacing with and driving data lines in bus-organized systems. The device is characterized for operation over a temperature range of -40°C to +85°C.
| Operating Temperature Range | -40°C to 85°C |
|---|---|
| Supply Voltage (VCC) | 3 V to 5.5 V |
The device is characterized for operation from -40°C to 85°C.
The outputs are disabled when G is high.
