This document explains the RemoTI HID dongle application and topics related to customizing the application. It describes the concepts and settings of the Texas Instruments RemoTI release for Zigbee RF4CE target node HID dongle development using the RemoTI release and the CC2531 USB dongle.
The guide details the features of the application, including compliance with Zigbee RF4CE network layer and CERC profile specifications, as well as HID-compliant keyboard and consumer control device capabilities. It provides an overview of the build configurations, project files, and the architecture of the RemoTI HID dongle component.
| Compliance | Zigbee RF4CE network layer specification |
|---|---|
| Profile | Zigbee RF4CE CERC profile |
| HID Type 1 | HID-compliant keyboard |
| HID Type 2 | HID-compliant consumer control device |
| LEDs | Two activity LEDs |
| USB Controller | USB controller |
| LED Control Pins | P1_0 and P1_1 |
| Key Switch Pins | P1_2 and P1_3 |
| DMA Channels | DMA channel 0, 1, and 2 |
| Timers | Timer2 and sleep timer |
This document explains the RemoTI HID dongle application and topics related to customizing the application.
The development uses the RemoTI release and the CC2531 USB dongle.
The application supports HID-compliant keyboard and HID-compliant consumer control device interfaces.
