WIZnet W5500 Manuals

ManualLib has 4 documents for the WIZnet W5500 (Other Electronics): 1 application note, 3 datasheets. Every file can be read online or downloaded as a PDF for free.

Application Note 1Datasheet 3

Key facts

Brand
WIZnet
Model
W5500
Industry
Electronics
Documents
4
Languages
EN · ZH
Last added
2026-11-13

Start here

Wiznet W5500 External Magnetic Component Reference Design

Wiznet W5500 External Magnetic Component Reference Design

Application Note 2 pages · 551 KB · EN

This document serves as a reference design for the Wiznet W5500 network interface chip. It details the external magnetic component layout and provides specific recommendations for hardware design optimization.

Key design guidelines include the application of damping resistors (specifically 33 ohms) for EMI reduction, avoiding the placement of power jacks near the RJ-45 connector, and voiding power and ground planes under discrete magnetic components. The document also specifies the use of stable power sources, high-quality CAT5E cables, and ferromagnetic beads between digital and analog voltage domains.

Read online

WIZnet W5500 specifications

Damping resistor value33 ohms
Ferromagnetic bead impedance100 to 2000 ohms at 100MHz
Filter capacitor value25MHz

Source: Wiznet W5500 External Magnetic Component Reference Design

All WIZnet W5500 documents by type

Application Note 1

How to use the product for one specific task, with worked examples.

Datasheet 3

Ratings, dimensions and ordering codes, for selection and design work.

Questions answered in these manuals

What damping resistor value is recommended for EMI reduction?

A 33 ohm resistor was found to be the best value for EMI reduction in this design.

From: Wiznet W5500 External Magnetic Component Reference Design

What impedance is adequate for a ferromagnetic bead between digital and analog power?

An impedance between 100 and 2000 ohms at 100MHz is considered adequate.

From: Wiznet W5500 External Magnetic Component Reference Design

What is the maximum SPI clock frequency?

The theoretical maximum SPI clock frequency is 80MHz.

From: WIZnet W5500 Ethernet Controller Datasheet V1.3

Does the W5500 support automatic polarity transformation (MDIX)?

No, it does not support automatic MDIX; users must use straight-through or crossover cables manually.

From: WIZnet W5500 Ethernet Controller Datasheet V1.3

How many hardware sockets does the W5500 support?

It supports eight independent hardware sockets for simultaneous communication.

From: WIZnet W5500 Datasheet

What is the maximum SPI clock frequency for the W5500?

The SPI interface can operate at up to 80 MHz.

From: WIZnet W5500 Datasheet
