UTC LM324 Quad Operational Amplifier Datasheet
The UTC LM324 is a quad operational amplifier offering four independent, high‑gain, internally frequency‑compensated op‑amps in a DIP‑14 package. It operates from a single supply voltage of 3 V to 32 V and can also be used with split supplies, making it suitable for transducer amplifiers, DC gain blocks, and standard op‑amp circuits.
Key features include a large DC voltage gain of 100 dB, input common‑mode voltage that includes ground, and a wide output swing from ground to VCC‑1.5 V. The datasheet provides ordering information for various package types, absolute maximum ratings, and detailed electrical characteristics such as supply current, offset voltage, and frequency response.
UTC LM324 specifications
| Supply Voltage Range | 3 V ~ 32 V |
|---|---|
| DC Voltage Gain | 100 dB |
| Input Common‑Mode Voltage | Includes ground |
| Output Voltage Swing | From 0 V to VCC‑1.5 V |
| Power Supply Current (VCC=5 V) | 0.7 ~ 12 mA |
All UTC LM324 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What supply voltage range does the UTC LM324 support?
It operates from a single supply voltage of 3 V up to 32 V.
What is the DC voltage gain of the LM324?
The device provides a large DC voltage gain of 100 dB.
What is the supply voltage range for the UTC LM324?
The LM324 operates from 3 V up to 32 V.
How many operational amplifiers are integrated in the LM324?
The LM324 contains four independent operational amplifiers.
