Key facts
- Brand
- Hayward
- Model
- 2100 Series
- Documents
- 3
- Languages
- EN
- Last added
- 2012-08-06
Start here
Hayward 2100 Series Pool System Control Installation and Programming Instructions
This manual provides installation and programming instructions for the Hayward 2100 Series Pool System Control. Designed for ease of use, this master remote control allows monitoring and setting up to 12 functions necessary for total pool system control as well as pool environment control.
The document covers safety precautions regarding water entrapment and electrical shock, detailed electrical specifications for various components like heaters and pumps, and step-by-step guides for installing the main control center, master control panel, and optional RF panels. It also includes instructions for configuring the system and troubleshooting common issues.
Hayward 2100 Series specifications
| Main Control Panel Dimensions (Width x Height x Depth) | 7 1/2" x 5 1/2" x 1 1/2" |
|---|---|
| Spa Side Control Panel Dimensions (Width x Height x Depth) | 5 7/8" x 2 3/4" x 7/8" |
| Main Control Center Dimensions (Width x Height x Depth) | 16 1/2" x 16 1/2" x 4 1/2" |
| Maximum System Amperage (Basic) | 50A MAX. |
Source: Hayward PSC 2100 Series Pool System Control Installation and Programming Instructions
All Hayward 2100 Series documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
What is the maximum safe water temperature for an adult in this spa?
The water should never exceed 104°F (40°C), and temperatures between 100°F (38°C) and 104°F (40°C) are considered safe.
From: Hayward 2100 Series Pool System Control Consumer Operating Instructions
How far must electrical appliances be kept from the pool or spa?
Do not permit any electrical appliance within 5 feet (1.5M) of a pool or spa.
From: Hayward 2100 Series Pool System Control Consumer Operating Instructions
What is the maximum recommended water temperature for a spa?
The water in a spa should never exceed 104°F (40°C).
From: Hayward PSC 2100 Series Pool System Control Installation and Programming Instructions
What safety distance must be maintained between electrical equipment and the pool wall?
The Main Control Center must be installed at least 5 feet from the inside wall of the pool or spa.
From: Hayward PSC 2100 Series Pool System Control Installation and Programming Instructions
What is the maximum safe water temperature for a spa?
The water in a spa to which the Control System is connected should never exceed 104°F (40°C).
From: Hayward 2100 Series Pool System Control Installation and Programming Instructions
What are the symptoms of hyperthermia?
Symptoms include dizziness, fainting, drowsiness, lethargy, and an increase in internal body temperature.
From: Hayward 2100 Series Pool System Control Installation and Programming Instructions
