Start here
DENSITRON DD-12964WE-1A W3030 3 V Dual-Mode IF Cellular Receiver
The DD-12864WE-1A is a 128 × 64 dot monochrome white OLED display module with a passive‑matrix (0.96") display mode and a SH1101A driver IC. It is designed for compact applications, measuring 26.70 × 19.26 × 2.10 mm (glass) and weighing only 2 g.
The document provides full mechanical, electrical, optical and functional specifications, as well as reliability test results and handling precautions such as cleaning methods, static‑charge protection, and recommended storage conditions.
Densitron DD-12864WE-1A specifications
| Display Format | 128 × 64 Dots |
|---|---|
| Overall Dimensions (Glass) | 26.70 × 19.26 × 2.10 mm |
| Active Area | 21.74 × 10.86 mm |
| Driver IC | SH1101A |
| Supply Voltage (Vppi) | -0.3 V to 3.5 V |
| Operating Temperature | -30 °C to +70 °C |
Source: DENSITRON DD-12964WE-1A W3030 3 V Dual-Mode IF Cellular Receiver
All Densitron DD-12864WE-1A documents by type
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the supply voltage range for the DD-12864WE-1A module?
The module operates with a supply voltage (Vppi) from –0.3 V up to 3.5 V.
From: DENSITRON DD-12964WE-1A W3030 3 V Dual-Mode IF Cellular Receiver
What are the recommended operating temperature limits?
The display can operate between –30 °C and +70 °C.
From: DENSITRON DD-12964WE-1A W3030 3 V Dual-Mode IF Cellular Receiver
Which pins form the 8‑bit data bus on the DD-12864WE-1A?
Pins DO0‑DO7 constitute an 8‑bit bi‑directional data bus that connects to the MCU’s data bus.
From: Densitron DD-12864WE-1A with EVK Board Application Note
How is the reset signal applied to the DD-12864WE-1A?
The RES pin is the reset signal input; pulling it low initiates chip initialization.
From: Densitron DD-12864WE-1A with EVK Board Application Note
