Dell R905 Manuals

ManualLib has 4 documents for the Dell R905 (SERVER): 3 user manuals, 1 quick start guide. Every file can be read online or downloaded as a PDF for free.

User Manual 3Quick Start Guide 1

Key facts

Brand
DELL
Model
R905
Category
SERVER
Industry
Computers
Documents
4
Languages
ZH · EN
Last added
2026-10-08

Start here

DELL R905system system Quick Start Guide

DELL R905system system Quick Start Guide

Quick Start Guide 58 pages · 3.8 MB · EN

The Dell PowerEdge R905 is a rack‑mountable server that supports two or four AMD Opteron™ 8000 Series processors, up to 128 GB of DDR2 memory, hot‑plug SAS drives, and redundant 1100 W power supplies. It includes integrated networking, TPM security, and optional remote access controller options.

This Quick Start Guide provides an overview of system features, lists supported operating systems, and walks you through unpacking, rack installation, connecting peripherals, and initial power‑on procedures. It also points to additional documentation such as the Hardware Owner’s Manual and Rack Installation Guide for deeper configuration details.

Read online

Dell R905 specifications

Processor typeTwo or four dual‑ or quad‑core AMD Opteron™ 8000 Series processors
Memory architecture667 MHz registered DDR2 (standard) and 800 MHz registered DDR2 (limited configurations)
Maximum RAMTwo processors: 64 GB; Four processors: 128 GB (256 GB with 8 GB modules)
Expansion slotsTwo half‑length x8 slots and five half‑length x4 slots (one x4 reserved for SAS controller)
Power suppliesTwo hot‑pluggable 1100 W high‑efficiency redundant power supplies

Source: DELL R905system system Quick Start Guide

All Dell R905 documents by type

User Manual 3

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Quick Start Guide 1

The shortest path to a working setup, usually only a few pages.

Questions answered in these manuals

How do I replace the system battery?

Refer to the section titled “更换系统电池” which provides step‑by‑step instructions for battery replacement.

From: Dell PowerEdge R905 Hardware User Manual

How can I disable a forgotten password?

The manual explains the procedure under “禁用已忘记的密码” in the system setup program chapter.

From: Dell PowerEdge R905 Hardware User Manual

What does a NOTE indicate in this manual?

A NOTE indicates important information that helps you make better use of your computer.

From: Dell PowerEdge R905 Hardware Owner's Manual

What does the LCD status message E1610 PS # Missing mean?

It means the specified power supply is improperly installed or removed.

From: Dell PowerEdge R905 Hardware Owner's Manual

Which Dell servers does this guide use as consolidation targets?

The guide uses the Dell PowerEdge R900 and PowerEdge R905 as target servers.

From: Dell PowerEdge R900/R905 SQL Server Consolidation Guide

What platform does the guide use to consolidate SQL Server instances?

It consolidates SQL Server instances from multiple machines onto a single Windows Server 2008 system using Microsoft's Hyper-V.

From: Dell PowerEdge R900/R905 SQL Server Consolidation Guide
