Altera MAX 10 FPGA Development Kit User Guide
This document is the user guide for the Altera MAX 10 FPGA Development Kit. It describes the board components, getting started steps, software installation, USB-Blaster driver installation, and the board test system.
It also covers configuration, switches and jumpers, clocks, memory, Ethernet, HDMI, HSMC, Pmod connectors, power distribution, and compliance information. This manual is written in Chinese.
Altera MAX 10 specifications
| Supported Configuration Schemes | JTAG configuration and Internal configuration |
|---|---|
| Supported Features for JTAG | SEU Mitigation |
| Supported Features for Internal | Remote System Upgrade, Compression, Design Security, SEU Mitigation |
| CFM Sectors (10M04 and above) | Three sectors: CFM0, CFM1, and CFM2 |
| CFM Sectors (10M02) | One sector: CFM0 |
| Programming Time CFM0 (10M02) | 5.4 seconds |
| Programming Time CFM0 (10M40/50) | 52.9 seconds |
| JTAG Pin Standards | LVTTL/ LVCMOS 3.3-1.5V |
All Altera MAX 10 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What configuration schemes are supported by MAX 10 devices?
MAX 10 devices support JTAG configuration using the JTAG interface and internal configuration using internal flash.
Does JTAG configuration support Remote System Upgrade?
No, JTAG configuration does not support Remote System Upgrade, Compression, Design Security, or SEU Mitigation.
What are the supported speed grades for MAX 10 devices?
The supported speed grades range from –C7 (slowest) to –A7 (fastest), depending on the device grade.
What is the maximum allowed overshoot voltage for a 11.4-year time frame?
The maximum allowed overshoot voltage is 4.12 V, which allows for 100% of the high time duration.
What software is included with the kit?
The kit includes free Quartus II Web Edition design software, downloaded from the website.
How do I install the USB-Blaster driver?
The onboard USB-Blaster II driver installation wizard is available on the Altera website.
