The TPK AS-700 manual provides safety guidelines, setup steps, temperature control, calibration and maintenance instructions for the intelligent lead‑free…
This manual introduces the TPK AS-700 intelligent lead‑free soldering station, featuring dual‑temperature LCD display, fast high‑frequency heating, digital calibration and ESD protection. It outlines the product’s key characteristics, specifications and recommended usage for lead‑free soldering.
Detailed sections cover safe operation, installation, temperature setting, calibration procedures, password protection, sleep and shutdown timers, soldering‑iron‑head selection, routine maintenance, error codes and component replacement, ensuring reliable performance and longevity of the device. This manual is written in Chinese.
| Power | 180W |
|---|---|
| Output voltage | AC 36V, 400kHz |
| Temperature range | 50 °C – 600 °C |
| Maximum ambient temperature | 40 °C |
| Temperature stability | ±2 °C (no load) |
| Dimensions (L×W×H) | 245 mm × 100 mm × 200 mm |
| Handle cable length | 1.8 m (customizable) |
| Weight | 2.8 kg |
| Heating element type | Electromagnetic |
| Ground potential of iron tip | < 2 mV |
Enter calibration mode by holding the * key and pressing ▲ and ▼ together, then use the LCD prompts to input the measured temperature values from a temperature tester, confirming each digit with the * key.
