This document provides a product catalog for Token's high voltage resistor series, including specifications and applications for various models.
This document is a comprehensive product catalog from Token Industrial Co., Ltd. detailing their range of high voltage resistors. It covers terminology, general specifications, electronic characteristics, part number identification, environmental test conditions, dimensions, electrical properties, derating curves, and specific series descriptions.
The catalog includes detailed information for multiple resistor types such as leadless ceramic chip resistors (RMCA, RMCB), metal-cermet damping resistors (RMCC), tubular ceramic non-inductive high voltage resistors (RMCD), and various glass glaze film models. It also provides application examples like automotive ignition systems and surge current limiters. This manual is written in Chinese.
| Operating Temperature | -40°C~155°C |
|---|---|
| Resistance Tolerance | K(±10%), M(±20%) |
| Rated Power | Up to 5W |
These resistors operate between -40°C and 155°C.
They are suitable for muffler engine ignition systems.
