Technical specifications for Token XT MB Series ceramic trap filters used for video and sound IF attenuation in TV/VCR stages.
This datasheet provides technical specifications for the Token XT MB Series, which are band-reject type ceramic filters designed for video and sound intermediate frequency (IF) attenuation in TV and VCR stages. The filters are compatible with the Murata TPS MB Series and cover a frequency range from 3.58 MHz to 6.5 MHz.
The document details the technical characteristics for various models, including center frequency, minimum attenuation, and 30 dB attenuation bandwidth. It also includes physical dimensions, a test circuit diagram, attenuation characteristics graphs, and ordering information. This manual is written in Chinese.
| Product Type | Band reject type ceramic filters |
|---|---|
| Frequency Range | 3.58 MHz ~ 6.5 MHz |
| Compatibility | Murata TPS MB Series |
| Center Frequency (XT3.58MB) | 3.580 MHz |
| Minimum Attenuation (XT3.58MB) | 25 dB |
| 30dB Attenuation BW (XT3.58MB) | 40 kHz |
| Center Frequency (XT6.5MB) | 6.500 MHz |
| Minimum Attenuation (XT6.5MB) | 35 dB |
The XT MB Series covers a frequency range from 3.58 MHz to 6.5 MHz.
Yes, the XT MB Series is compatible with the Murata TPS MB Series.
The minimum attenuation for the XT3.58MB model is 25 dB.
