Featured Token manuals
Token Electronics XTMB Series Ceramic Trap Filter Datasheet
The XTMB series ceramic trap filters from Token Electronics are designed for TV and VCR stage applications, providing video and sound IF attenuation. Each filter contains two trap elements on a single substrate, allowing additional attenuation in the signal path.
Technical characteristics include center frequencies from 4.5 MHz to 6.5 MHz, minimum attenuation of 30 dB at the center frequency, and attenuation bandwidths ranging from 40 kHz to 90 kHz. The datasheet also provides a test circuit diagram and contact information for ordering. This manual is written in Chinese.
Covers: Technical Characteristics · Part Numbers · Center Frequency · Attenuation · Attenuation Bandwidth · Test Circuit
Token LTM 455/450 Series Ceramic Filters Datasheet
The LTM 455/450 series ceramic filters are high‑selectivity components designed for communication applications such as two‑way radios and transceivers. The datasheet provides detailed electrical characteristics, mechanical dimensions, and ordering codes for each filter variant.
In addition to the LTM series, the document covers Token's other ceramic filter families—including LTB, LTT, LZU, LTZ, LTP, LTCS10.7M, and LTS MCB/MDB—offering specifications for TV/VCR, AM, FM, and other frequency ranges, as well as packaging and soldering guidelines.
Covers: LTM 455/450 Series Technical Characteristics · LTB Series Specifications · LTT High‑Selectivity Series · LZU Search‑Stop Series · LTZ AM Series · LTP AM Series
Token Electronics XT MJ/MB Ceramic Trap Filter Datasheet
The XT MJ/MB ceramic trap filter series from Token Electronics provides band‑reject performance for video and sound IF attenuation. The two‑terminal devices are compatible with Murata TPS MJ series parts and are used to suppress chrominance carriers in video or sound signals in B/W receivers.
The datasheet lists part numbers, center frequencies, minimum attenuation and bandwidth for each model, along with a test circuit diagram and ordering information.
Covers: Technical Characteristics · Dimensions · Test Circuit · How to Order
Latest Token manuals
Token Electronics XTMB Series Ceramic Trap Filter Datasheet
Datasheet 2 pages · 65 KB · ZHThe Token Electronics XTMB Series ceramic trap filters are band‑reject filters for TV/VCR video and audio IF attenuation, covering 4.5‑6.5 MHz with up to…
Token LTM 455/450 Series Ceramic Filters Datasheet
Datasheet 35 pages · 820 KB · ENTechnical specifications, dimensions, and ordering information for Token's LTM 455/450 series ceramic filters and related product lines.
Token Electronics XT MJ/MB Ceramic Trap Filter Datasheet
Datasheet 1 pages · 272 KB · ENTechnical specifications for Token Electronics' XT MJ/MB ceramic trap filter series, including frequency, attenuation and bandwidth data.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Token manuals
What frequency range do the XTMB series filters cover?
The XTMB series filters cover a center frequency range from 4.5 MHz to 6.5 MHz.
From: Token Electronics XTMB Series Ceramic Trap Filter Datasheet
How many trap elements are on each XTMB filter substrate?
Each XTMB filter substrate contains two trap elements.
From: Token Electronics XTMB Series Ceramic Trap Filter Datasheet
What is the operating temperature range for the LTB series filters?
The LTB series operates from –20 °C to +80 °C, and can be stored from –40 °C to +85 °C.
What is the recommended peak temperature for reflow soldering of Token ceramic filters?
The recommended peak temperature is 240 °C maximum.
What is the center frequency of the XT3.58MJ filter?
The XT3.58MJ filter has a center frequency of 3.580 MHz.
From: Token Electronics XT MJ/MB Ceramic Trap Filter Datasheet
What is the minimum attenuation of the XT4.5MJ filter?
The XT4.5MJ filter provides a minimum attenuation of 20 dB at its center frequency.
From: Token Electronics XT MJ/MB Ceramic Trap Filter Datasheet
